Docma VF155-AUTOMATIC Petrol Forestry Winch + 5X80M Rope Code 980004

DOCMA VF155 AUTOMATIC Ultralight Petrol Forestry Winch with Ø5 mm x 80 m Textile Rope – Code 980004

The DOCMA VF155 AUTOMATIC Ultralight forestry winch represents excellence in wood handling and recovery in forestry, agriculture, and professional applications. Designed and manufactured in Italy , it is the result of years of DOCMA research in the field of high-performance portable winches.

Thanks to its compact, robust and ultra-light structure, the VF155 AUTOMATIC guarantees high power, maximum reliability and operational safety , even in the most demanding working conditions.

High performance and maximum versatility

The DOCMA VF155 winch offers a maximum pull of 1,485 kg in direct pull , which can reach 2,970 kg in double pull using a return pulley. These performances make it ideal for:

• professional forestry work

• logging and log recovery

• controlled culling

• movement of heavy loads in difficult areas

The powerful 50.8cc SOLO HP50E-A petrol engine , made in Germany, ensures quick starts, smooth operation and reduced maintenance requirements .

AUTOMATIC system with integrated rope guide

The real strong point of the VF155 AUTOMATIC is the innovative automatic rope winding system , equipped with an integrated rope guide , which guarantees:

• neat and uniform winding

• reduction of the risk of drum blockages

• longer life of the rope

• greater safety during use

The winch is supplied with 80 metres of Ø 5 mm Dyneema textile rope , which is extremely abrasion-resistant, lightweight and much easier to handle than steel ropes.

Lightweight, compact and easy to carry

Weighing just 25 kg (without cable) , the DOCMA VF155 AUTOMATIC Ultralight is one of the lightest forestry winches in its class. The compact and balanced design allows:

• easy to carry even by hand

• quick positioning at the workplace

• safe use even in confined spaces

The anchoring system is simple and quick, thanks to the rear loop and the hooks with safety catches supplied.

Total security and control

The winch is equipped with:

• immediate-action automatic brake

• mechanical bell clutch

• ergonomic controls that are easy to operate even with gloves

• clearly visible off switch

Each component is designed for intensive and professional use , ensuring reliability over time.

Main technical features

• Model: DOCMA VF155 AUTOMATIC Ultralight

• Product Code: 980004

• Engine: ONLY HP50E-A – 2-stroke – 50.8 cc

• Power: 2.58 HP / 2.3 kW

• Direct drive: 1,485 kg

• Double traction: 2,970 kg

• Winding speed: 20 m/min

• Rope: Dyneema Ø 5 mm – length 80 m

• Rope winding: Automatic with rope guide

• Brake: Automatic

• Weight: 25 kg (without rope)

• Dimensions: 59 × 36 × 36 cm

• Production: Made in Italy

Equipment included

• DOCMA VF155 AUTOMATIC Winch

• Dyneema textile rope Ø 5 mm x 80 m

• Tow hook

• 4 m ring sling – 20 quintals

• Instruction manual

Why choose the DOCMA VF155 AUTOMATIC

✔ High professional performance
✔ Low weight and maximum portability
✔ Exclusive automatic winding system
✔ Ultra-light and resistant textile rope
✔ DOCMA build quality
✔ Ideal for intensive forestry work
