DAB VB 35/120 Domestic Wet Rotor Circulator - 60112933

DAB VB 35/120 Wet Rotor Circulator - 60112933

Product packed in a NON original box

The DAB VB 35/120 circulator is a compact, quiet, and efficient wet rotor pump designed for heating, air conditioning, and water supply systems in domestic and industrial settings. Thanks to its cast iron body and technopolymer impeller, it guarantees reliability, long life, and resistance even under continuous use.

Easy to install, this model is suitable for systems with clean liquids, free of mineral oils and abrasive substances, with characteristics similar to those of water.

Technical features

• Model: DAB VB 35/120 - 60112933

• Type: Wet rotor circulator

• Pump body material: Cast iron

• Impeller material: Technopolymer

• Motor: Wet rotor asynchronous

• Protection class: IP44

• Insulation class: F

• Power supply: Single-phase 230V / 50 Hz

• Maximum power: 78 W

• Rotation speed: 3 selectable speeds (2465 / 1930 / 1150 rpm)

• Maximum flow rate: 3 m³/h

• Maximum head: 4.3 m

• Maximum operating pressure: 10 bar

• Maximum glycol content: 30%

• Liquid temperature: -10°C to +110°C

• Installation: Horizontal shaft

• Connections: DN 25 (standard) – DN 20/DN 32 (special kit)

• Dimensions (WxDxH): 120 x 104 x 124 mm

• Weight: 2.7 kg

Advantages of the DAB VB 35/120 circulator

• Quiet operation , ideal for home installations.

• Compact and lightweight , easy to install even in small spaces.

• 3 adjustable speeds , to optimize consumption according to needs.

• Durable materials (cast iron and technopolymer) for long life.

• Reliable : suitable for heating, cooling and domestic hot water.

Recommended applications

• Domestic and industrial heating systems.

• Air conditioning and cooling systems.

• Water distribution with clean water.

• Applications with neutral, non-viscous liquids and without abrasive substances.

Limitations of use

• Not suitable for water with solid particles or mineral oils.

• Not suitable for aggressive or viscous liquids.
